QCB Thermoplastic Bearing Units

Brand Overview

QCB Thermoplastic Bearing Units provide a lightweight, corrosion-resistant and hygienic alternative to traditional cast iron housed bearings. Manufactured from high-grade glass-filled PBT thermoplastic polyester, these bearing units are designed for applications where cleanliness, chemical resistance and frequent washdown are essential. Unlike coated metal housings, QCB Thermoplastic Bearing Units will not rust, corrode, chip or peel, making them an ideal choice for food processing, pharmaceutical, beverage and chemical industries.

Each housing is fitted with a precision AISI 440 stainless steel bearing insert, stainless steel bolt inserts and grease nipples, and is factory-filled with FDA-approved food-grade grease. The result is a maintenance-friendly bearing unit that offers outstanding durability, excellent dimensional stability and long service life in demanding operating environments.

As an authorised QCB distributor, NBC Group stocks one of the UK’s largest ranges of QCB Thermoplastic Bearing Units, supported by expert technical advice, application engineering and fast worldwide delivery.

Product Range

QCB Thermoplastic Bearing Units are available in a comprehensive range of housing styles to suit almost every industrial application.

Housing Styles

• PPL Two-Bolt Pillow Block Units
• UCPL Tapped Base Pillow Blocks
• FPL Four-Bolt Flange Units
• NFL Two-Bolt Oval Flange Units
• FBL Flange Bracket Units
• HPL Hanger Units
• TPL Take-Up Units
• Stainless Steel Bearing Inserts
• Plastic Bearing Inserts
• Open and Closed End Covers

Product Features

• High-grade glass-filled PBT thermoplastic housings
• AISI 440 stainless steel bearing inserts
• 304 stainless steel bolt inserts and grease nipples
• FDA-approved food-grade grease
• Metric and imperial bore sizes
• Bore sizes from 12 mm to 50 mm (½” to 2″) available from stock
• Open or closed shaft end covers
• Direct interchange with conventional cast iron housed units

QCB Thermoplastic Bearing Units are dimensionally interchangeable with many standard cast iron bearing units, making them an ideal upgrade where corrosion resistance and hygiene are priorities.

Applications

QCB Thermoplastic Bearing Units are widely used wherever equipment is regularly exposed to moisture, aggressive cleaning chemicals or strict hygiene requirements.

Typical applications include:

• Food Processing
• Beverage & Bottling Plants
• Dairy Production
• Pharmaceutical Manufacturing
• Chemical Processing
• Packaging Machinery
• Canning Equipment
• Conveyor Systems
• Water Treatment Plants
• Marine & Coastal Installations
• Agricultural Equipment
• Washdown Production Areas
• General Industrial Machinery

Their corrosion-resistant and non-magnetic construction makes them particularly suitable for environments where conventional cast iron housings would deteriorate or where product contamination must be avoided.

Technical Information

QCB Thermoplastic Bearing Units combine the strength of engineered polymers with precision stainless steel bearing technology to provide a durable, maintenance-friendly housed bearing solution.

Manufactured from glass-filled PBT thermoplastic polyester, the housings offer excellent tensile strength, dimensional stability and resistance to impact, chemicals and hot water washdown. Unlike painted or plated cast iron housings, the solid thermoplastic construction cannot rust, chip or peel, ensuring long-term protection even in harsh operating conditions.

Key Features

• Glass-filled PBT thermoplastic housing
• AISI 440 stainless steel bearing inserts
• 304 stainless steel fixing inserts and grease nipples
• FDA-approved food-grade grease
• Smooth hygienic surface finish
• Corrosion and chemical resistant
• Non-magnetic construction
• Pressure washable with hot water
• Operating temperature from -35°C to +102°C
• Excellent dimensional stability
• Lightweight yet extremely durable
• Interchangeable with cast iron housed units

Engineering Support

NBC Group’s technical team can assist with:

• Bearing unit selection
• Hygienic design recommendations
• Product interchange
• OEM specifications
• Food industry applications
• Corrosion-resistant upgrades
• Replacement bearing identification
• Preventative maintenance programmes

With over 65 years of engineering experience, NBC Group supports customers across the food, beverage, pharmaceutical, chemical and manufacturing industries with expert advice and fast product availability.

Frequently Asked Questions

What are QCB Thermoplastic Bearing Units?

QCB Thermoplastic Bearing Units are complete housed bearing assemblies manufactured from glass-filled PBT thermoplastic with stainless steel bearing inserts. They are designed to provide corrosion resistance, hygienic performance and long service life in demanding environments.

What are the advantages of thermoplastic bearing housings?

Thermoplastic housings will not rust, corrode, chip or peel like painted cast iron housings. They are lightweight, chemically resistant, easy to clean and ideal for washdown environments where hygiene is critical.

Which industries use QCB Thermoplastic Bearing Units?

They are widely used in food processing, beverage production, dairy, pharmaceutical manufacturing, chemical processing, packaging, canning, water treatment and other industries where corrosion resistance and cleanliness are essential.

Are the bearing inserts stainless steel?

Yes. QCB Thermoplastic Bearing Units are fitted with AISI 440 stainless steel bearing inserts, while the bolt inserts and grease nipples are manufactured from 304 stainless steel to maximise corrosion resistance.

What grease is used?

The bearing inserts are factory-filled with FDA-approved food-grade grease, making them suitable for hygiene-sensitive and food production environments.

Are QCB Thermoplastic Bearing Units interchangeable with cast iron units?

Yes. The complete range is dimensionally interchangeable with many standard cast iron housed bearing units, allowing existing equipment to be upgraded quickly without major modifications.

Why choose QCB Thermoplastic Bearing Units?

QCB Thermoplastic Bearing Units combine corrosion resistance, hygienic design and dependable performance in a lightweight, maintenance-friendly package. With engineered PBT housings, stainless steel inserts, food-grade lubrication and a wide range of housing styles, they are an ideal solution for demanding industrial applications. Backed by NBC Group’s technical expertise and extensive stockholding, they provide reliable performance and excellent long-term value.
