Series Z
Type L – Suitable for farm vehicles at speeds 30 km/h Usually supplied undrilled, but painted with black primer Should never be welded to the mounting frame Lubricate with Lithium or Lithium-Calcium EP2 grease Need help? Phone the experts on 01952 222300 or e-mail slewingrings@nbcgroup.co.uk
Our engineers design, manufacture, and supply components to your exact specification. Contact us to discuss your project.
Type L & N – JOST trailer rings for farm vehicles at speeds
|
NBC Stock code |
Dimensions |
Weight |
Allowable |
|||||||
|
A |
B |
C |
D |
E |
F |
G |
H |
axial load |
||
|
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(kg) |
(kN) |
|
|
|
||||||||||
|
400L |
400 |
342 |
292 |
230 |
375 |
260 |
8 |
45 |
11 |
7.5 |
|
500L |
500 |
442 |
392 |
330 |
475 |
360 |
15 |
9 |
||
|
650L |
650 |
592 |
542 |
480 |
625 |
510 |
20 |
15 |
||
|
750L |
750 |
692 |
642 |
580 |
725 |
610 |
23 |
18 |
||
|
850L |
850 |
792 |
742 |
680 |
825 |
710 |
27 |
25 |
||
|
950L |
950 |
892 |
842 |
780 |
925 |
810 |
30 |
30 |
||
|
1050L |
1050 |
992 |
942 |
880 |
1025 |
910 |
34 |
35 |
||
|
|
||||||||||
|
Z400-14T (400N) |
400 |
334 |
281 |
215 |
375 |
240 |
8 |
52 |
15 |
14 |
|
500N |
500 |
437 |
384 |
315 |
475 |
340 |
19 |
18 |
||
|
650N |
650 |
587 |
534 |
465 |
625 |
490 |
25 |
25 |
||
|
750N |
750 |
687 |
634 |
565 |
725 |
590 |
30 |
30 |
||
|
850N |
850 |
787 |
734 |
665 |
825 |
690 |
35 |
35 |
||
|
950N |
950 |
887 |
834 |
765 |
925 |
790 |
40 |
40 |
||
|
1050N |
1050 |
987 |
934 |
865 |
1025 |
890 |
50 |
45 |
||
Warning: Undefined array key "alt" in /home/nbcgroup/public_html/app/themes/wmm/template-parts/products/tab-repeater.php on line 208
Interchange information
The table below lists generally accepted interchange information. Please be aware that the heights of trailer rings can vary considerably – these are not precise units, therefore in practice a small section height variance can usually be accomodated.
|
NBC ref
|
Equivalent part numbers
|
||||
|
|
|
|
|
|
|
|
400L
|
|
16L/400 (1)
|
310.14.0300.000 (1)
|
|
|
|
500L
|
|
16L/500 (1)
|
310.14.0400.000 (1)
|
|
|
|
650L
|
|
16L/650 (1)
|
310.14.0500.000 (1)
|
|
|
|
750L
|
|
16L/750 (1)
|
310.14.0600.000 (1)
|
|
|
|
850L
|
|
16L/850 (1)
|
310.14.0700.000 (1)
|
|
|
|
950L
|
|
16L/950 (1)
|
310.14.0800.000 (1)
|
|
|
|
1050L
|
|
16L/1050 (1)
|
310.14.0900.000 (1)
|
|
|
|
(1) Usually interchangeable, but total height 42mm
|
|||||
|
400N
|
Z 400.16
|
|
|
|
20119
|
|
500N
|
Z 500.16
|
16/500 (2)
|
320.16.0400.000 (2)
|
|
20124
|
|
650N
|
Z 650.16
|
16/650 (2)
|
320.16.0500.000 (2)
|
U01Z065
|
20127
|
|
750N
|
Z 750.16
|
16/750 (2)
|
320.16.0600.000 (2)
|
U01Z075
|
20120
|
|
850N
|
Z 850.16
|
16/850 (2)
|
320.16.0700.000 (2)
|
U01Z085
|
20121
|
|
950N
|
Z 950.16
|
16/950 (2)
|
320.16.0800.000 (2)
|
U01Z095
|
20122
|
|
1050N
|
Z 1050.16
|
16/1050 (2)
|
320.16.0900.000 (2)
|
U01Z105
|
20123
|
|
(2) Usually interchangeable, but total height 48mm
|
|||||
For any enquiries regarding Series Z, please complete our enquiry form, and a member of our technical team will respond promptly. Alternatively, you can reach out directly to one of our offices using the contact details here. Our specialists are ready to provide guidance and support tailored to your machinery and engineering needs.
